Non-tripping residual current:
≤0,5 IΔn
Temperatura ambiantă pentru montaj deschis:
-25°C bis +40°C
Lifetime, electric:
2000 Operations
Breaking capacity Im:
500
PROMO CODE GER:
6383-0095-02
Trigger time undelayed:
IΔn: ≤300ms;2 x IΔn: ≤150ms;≥5 x IΔn: ≤40ms
Terminal type:
Double Mouth Lift Clamp with Back clamps Protection
Temperatura maximă a mediului ambiant:
60
Stabilitate la impuls de tensiune Uimp:
4kV
Certificates:
VDE for type A in 2 pole version
Max. permissible back-up fuse against short circuit:
63
Descriere de bază:
Întreruptor diferenţial
Rezistenţă la scurtcircuit:
10
Capacitate de rupere nominala:
10
Valoare curent de defect :
30
Conductor masiv:
2.5 - 35
Dieelectric test voltage at ind. Frequence:
2500
Montaj:
On DIN rail according to EN 60715 (35mm) via quick mounting clip
Categorie produs:
F (sensibil la frecvente mixte)
Rated sensitivity IΔn:
30
Standard produs:
EN 61008-1:2012 + A1:2014 + A2:2014 + A11:2015 + A12:2017;EN 61008-2-1:1994 + A11:1998;EN 62423:2012
Max. allowed back-up fuse against thermal overload:
40A: 25A gG
Temperatura minimă a mediului ambiant:
-25
Tensiune nominală:
230V-AC
Descriere electrică CAD:
40A/2P/30mA/A
Insulation voltage:
500 V
Lifespan, mechanical:
10000 Operations
